Factory-calibrated MEMS accelerometer and gyroscope modules for guidance, navigation, and control applications.
Tactical-Grade MEMS Sensor Modules
Aeron's Castor family of Inertial Measurement Units delivers control-grade inertial sensor data for platforms that need reliable, factory-calibrated acceleration and angular-rate measurement — not a full navigation solution. Each module combines high-performance triaxial MEMS sensors with a high-speed onboard processor running digital signal processing and calibration algorithms, so every unit ships characterized and compensated for bias, misalignment, scale-factor error, and temperature drift.
The family spans a full 6DOF accelerometer + gyroscope + inclinometer module (IMU 1100), a dedicated gyroscope-only module for angular-rate-only applications (GYR 1200), and an OEM PCB-mounted 6DOF module built for high-speed SPI integration (IMU 1640) — giving system integrators the right sensor grade and interface for guidance, navigation, and control computers, robotics, gimbal stabilization, and unmanned ground and aerial platforms.
How Every Castor Module Works
IMU 1100, GYR 1200, and IMU 1640 all run the same onboard calibration and signal-processing approach — only the sensor suite and interface change between them.
Engineered for Control-Grade Precision
Nine core capabilities shared across the Castor IMU family.
Choose Your IMU
Castor IMU 1100
CSTR-IMU1100
A high-end tactical-class IMU combining a triaxial accelerometer, gyroscope, and inclinometer over a standard RS422 interface — factory calibrated and temperature compensated, suitable for guidance, navigation, and control systems, robotics, gimbal control, and unmanned ground and flight-control applications.
IMU 1100, GYR 1200 & IMU 1640 Series · Castor
Choose Your IMU
Castor IMU 1100
Miniature Tactical 6DOF IMU with RS422 Interface
A high-end tactical-class IMU combining a triaxial accelerometer, gyroscope, and inclinometer over a standard RS422 interface — factory calibrated and temperature compensated, suitable for guidance, navigation, and control systems, robotics, gimbal control, and unmanned ground and flight-control applications.
Sensors
Accelerometer, Gyroscope, Inclinometer
Gyro Bias Instability
0.7°/hr (typ.)
Interface
RS422
Update Rate
Up to 2000 Hz
Compare the Castor Family
IMU 1100, GYR 1200, and IMU 1640 — every spec, side by side.
| Sensor Suite | |||
Sensors | Accelerometer, Gyroscope, Inclinometer | Gyroscope only | Accelerometer, Gyroscope |
Gyro Bias Instability GYR 1200's single-axis-family design delivers the lowest gyro bias instability in the range | 0.7°/hr (typ.) | Best 0.6°/hr (typ.) | 1°/hr (typ.) |
Update Rate | Up to 2000 Hz | Up to 2000 Hz | Best Up to 4250 Hz |
| Communication & Interface | |||
Interface | RS422 | RS422 | SPI (15 Mbps) |
| Mechanical & Environmental | |||
Weight | 72 ± 3 g | 60 ± 4 g | Best 57 ± 3 g |
| Explore & enquire | View Product | View Product | View Product |
Why Choose Aeron
Aeron Systems focuses on innovation and high-precision engineering, prioritising sovereign control over critical technologies. Every Castor module is characterized and calibrated in-house for bias, misalignment, and temperature drift, then screened to military environmental and shock standards — so integrators get consistent, control-grade sensor data unit after unit, whether it's mounted standalone or built directly onto a customer's PCB.
Where Our IMUs Deliver
Field-proven performance across robotics, unmanned, and control platforms.
Guidance, Navigation & Control
Factory-calibrated accelerometer and gyroscope data feeding guidance and control computers across robotics and unmanned platforms.
Unmanned Ground Vehicles
Rugged, shock-qualified inertial sensing for UGV motion control and stabilization in demanding field conditions.
UAV Flight Control & Stabilization
High update-rate inertial data for drone flight controllers, gimbal stabilization, and attitude-hold systems.
Our Values
Factory-Calibrated Precision
Every sensor is characterized and calibrated in-house for bias, misalignment, scale-factor error, and temperature drift before it ships.
Flexible System Integration
Standalone RS422 modules or OEM SPI PCB-mount designs — built to drop into any control architecture without redesign.
Engineered for Extreme Environments
Qualified to MIL-STD-883F shock testing and a wide operating temperature range, with IP65 ingress protection across the family.
