Compare GNSS receivers
The Deneb receivers side by side.
| DNB-GBM200Man-Portable RTK Receiver | DNB-GN402RS232 + Ethernet Receiver | DNB-GN404Tactical Shock-Rated Receiver | |
|---|---|---|---|
| Accuracy | |||
| Horizontal Position | 1 cm CEP with RTK 1.5 m CEP Standalone | 1 cm CEP with RTK 1.5 m CEP Standalone | 1 cm CEP with RTK 1.5 m CEP Standalone |
| Vertical Position | 1 cm CEP with RTK 2 m CEP Standalone | 1 cm CEP with RTK 2 m CEP Standalone | 1 cm CEP with RTK 2 m CEP Standalone |
| Dynamic Heading Accuracy50% at 30 m/s dynamic operation | 0.03° (stronger) | 0.3° | 0.3° |
| Velocity Accuracy | 0.1 m/s | 0.1 m/s | 0.1 m/s |
| GPS / GNSS | |||
| Constellations*GN402 constellation support is factory upgradable | GPS, GLONASS, BeiDou, GALILEO, QZSS, NavIC | GPS, GLONASS, Galileo, BeiDou, IRNSS/NavIC, SBAS* | GPS, GLONASS, BeiDou, Galileo, QZSS, NavIC (IRNSS) |
| Channels | — | — | 1100+ (stronger) |
| Update Rate | 10 Hz | 10 Hz | 10 Hz |
| TTFF Cold Start | 60 sec | 45 sec (stronger) | 60 sec |
| Reacquisition Time | 2 sec | 2 sec | 15 sec |
| Protocols | NMEA 0183 RTCM v3.3 | NMEA 0183 RTCM v3 | NMEA 0183 (v2.3–v4.1) RTCM v3 |
| Antenna | |||
| Type | Multi-Constellation GNSS Antenna | Multi-Constellation GNSS Antenna | Multi-Constellation GNSS Antenna |
| Connector | SMA (GNSS ×1, RF ×1) | TNC Socket | TNC Female (Amphenol 122210) |
| Communication & Electrical | |||
| Input Voltage | 11.1 to 12.6 V DC | 12 to 32 V DC | 12 to 32 V DC |
| Power Consumption | — | < 3 W | 2.9 W (± 0.5 W) |
| Interfaces | RS232 ×1 | RS232 ×2, Ethernet ×1 PPS ×1 | RS232, RS422, Ethernet (all isolated) |
| Integrated Radio | 1 W · 865–867 MHz Transceiver (stronger) | — | — |
| LED Indicators | Power, Health, RF, GNSS/RTK | Power, Communication, Health | Power, Health, GNSS Fix, Communication |
| Physical | |||
| SizeGBM200 has the smallest footprint of the family | 156 × 80 × 56 mm (stronger) | 179 × 106.23 × 61.96 mm | 171.5 × 151.8 × 48.6 mm |
| Weight | < 1 kg (stronger) | < 1.5 kg | 1.1 kg (± 50 g) |
| Environmental | |||
| Operating Temperature | −40 to +71 °C | −40 to +71 °C | −40 to +71 °C |
| Storage Temperature | −55 to +85 °C | −55 to +85 °C | −55 to +85 °C |
| Ingress Protection | IP67 (stronger) | IP65 | IP65 |
| Survival Shock | — | — | Up to 500 g (MIL-STD-810G) (stronger) |
| EMI/EMC | MIL-STD-461E/F | MIL-STD-461E/F | MIL-STD-461F, JSS55555 |
| Environmental Tests | MIL-STD-810G | MIL-STD-810G | MIL-STD-810G, MIL-STD-704D |
Contact
Not sure which one fits? Tell one of our engineers about your platform and requirements and we will recommend a model, or ask for a price.
