Compare data loggers
Xtreme and Ace data loggers side by side.
| Ace DLG80C&I Solar & Agrivoltaic | Xtreme SDLIndustrial IoT Logger | Ace DLG88LAgri & Met Logger | |
|---|---|---|---|
| Core Performance | |||
| ADC ResolutionXtreme achieves >20 Effective Number of Bits | 24-bit | 24-bit (>20 ENOB) (stronger) | 12-bit Sigma-Delta |
| ADC Accuracy | ±0.1% FS | ±0.01% FS at 30 °C ±0.03% FS (full range) (stronger) | ±0.1% FS |
| Simultaneous Parameters | — | 1,000 (stronger) | 176 |
| Min. Logging Interval | 1 minute | 1 second (stronger) | 1 minute |
| Inputs & Interfaces | |||
| Analog Channels | 8 SE / 4 Differential | XG920: 8 SE / 4 Diff XG930: 16 SE / 8 Diff (stronger) | Davis & Aeron sensor suite |
| Signal Input Types | 0–500 mV · 0–1 V 4–20 mA · PT100 · PT1000 | 0–100 mV · 0–5 V 0–20 mA · PT100 · PT1000 | Aeron / Davis compatible |
| Digital I/O | — | 4 DI · 2 DO · 1 kHz (stronger) | — |
| Serial Interfaces | 2× RS485 Modbus RTU (Master + Slave) · RS232 | 2× RS232 · 3× RS485 SDI-12 | RS485 Modbus RTU SDI-12 |
| Modbus Role | Master & Slave | 2 Master & 1 Slave (stronger) | — |
| Connectivity | |||
| Wireless Network | 4G LTE | 4G LTE · Wi-Fi Bluetooth (stronger) | 4G LTE |
| Wired Network | — | Ethernet (stronger) | — |
| Protocols | Modbus RTU LTE cloud | Modbus RTU/TCP IEC 60870-5-101/104 SFTP · HTTP/HTTPS (stronger) | Modbus RTU LTE cloud |
| Cloud AnalyticsDLG80: real-time PR & CUF for solar plants | Aeron Live3 (PR & CUF analytics) (stronger) | Aeron Live3 | Aeron Cloud |
| Storage & Time | |||
| Primary Storage | 8 GB micro-SD | 8 GB internal + 8 GB SD (exp. 32 GB) (stronger) | 8 GB micro-SD (up to 32 GB) |
| Data Capacity | 5+ years | 5+ years | 5+ years |
| Data Retrieval | USB pen drive | USB · Web (local & remote) (stronger) | USB to laptop |
| Time Synchronisation | GPS | GPS · NTP · Cellular · Manual (stronger) | Network server (sync on connect) |
| Power & Physical | |||
| Power SupplyDLG88L: solar-ready with onboard battery backup | 9–28 V DC | 9–28 V DC (<10 W) | 9–28 V DC + Li-ion 5200 mAh + 20 W solar (stronger) |
| IP Rating | IP65 | IP65 | IP65 |
| Operating Temperature | — | −40 °C to +70 °C (stronger) | −20 °C to +70 °C |
| Housing | PC/ABS UV-resistant | PC UV-protected | ABS UV-protected |
| Dimensions (mm) | 170 × 125 × 67.5 | 231 × 125 × 90 | 125 × 170 × 66.5 |
| On-board Display | — | — | LCD 128×64 3-button keypad (stronger) |
| Standards & Application | |||
| IEC StandardXtreme also covers wind resource assessment | IEC 61724-1:2021 Class A | IEC 61724-1:2021 + IEC 61400-12-1:2022 (stronger) | — |
| CE Compliance | EN 61326-1:2021 | EN 61326-1:2013 | — |
| Primary Application | C&I Solar Plants Agrivoltaic monitoring | Solar · Wind · Environment Industrial IIoT | Agriculture Meteorology |
| Product Code(s) | 23009 | 24008 / 24009 | 23005 – 23008 |
Contact
Not sure which one fits? Tell one of our engineers about your platform and requirements and we will recommend a model, or ask for a price.
